Motion Control Suspension is a boutique/custom manufacturer of motorsport vehicle damper systems.

The MCS brand is chosen by owners of prestige performance vehicles, track/club day specialist & professional race teams. The MCS damper system provides superior handling & exceptional ride control that cheaper brands can't provide.

MCS struts/shocks have been fitted regularly in Australia on vehicles used for street/track day cars, Improved Production, Production car racing & Targa Tarmac Rally vehicles covering a wide range of vehicle brands.

MCS dampers have been supplied to & used for Ferrari & Maserati dealers/workshops when OEM replacement units are no longer in production.

Systems not in stock are built in the USA with a build/delivery time of up to 4 weeks for off the shelf production lengths & up to 8 weeks for custom/one off strut leg setups.

We stock service & replacement parts as the Australian authorized service representative.

Please check our vehicle brand listing for specific models if you are seeking a complete bolt in system.

Motion Control Suspension Strut features -

• Non remote or remote canister system
• Gas pressurized 100 to 280psi (system/valving dependent)
• Maintenance free nitrogen gas chamber on non-remote systems
• Gas pressure adjustable on remote canister systems to assist as a tuning tool
• Light weight aircraft grade hard anodized black aluminum body for shock arrangements front & rear
• Lightweight high grade steel strut bodies for McPherson strut setups front & rear
• Steel strut body increases torsional stiffness from lateral loads at a higher level exceeding inverted cartridge two piece designs while maintaining sufficient travel, more tyre to spring clearance & a wide range of ride height adjustability
• Shaft diameters of 16mm (shocks) or 22mm (shocks & struts) increase low speed sensitivity control
• Ride height adjustable
• Coil over or non-coil over available
• High load, low wearing German mono-ball bearings are used in the mounting plates (application dependent)

• Suspension/body attachments as pin to eye, eye to eye, pin to clevis or eye to clevis
• Fixed or custom lengths available (TC apply)
• Modular design, can be repaired and serviced locally by us
• Eliminates harshness of road surface due to high internal efficiency of the oil flow within the shock without sacrificing performance handling
• Outstanding repeatability and performance
• Supplied with ride height adjustment tools
• Spring collars/locator hardware included (application dependent)
• Up to 3-year warranty when purchased through Racing Shocks Australia
• Extended warranty available up to 5 years (T&C apply)
• After sales phone support

• 1 way non remote (1WNR) wide range of adjustment on rebound, minor on compression
• 2 way non remote (2WNR) wide range of adjustment on compression & rebound (separate adjusters)
• 2 way remote canister system (2WRC) wide range of adjustment on compression & rebound (separate adjusters)
• 3 way remote canister system (3WRC) low speed & high speed compression adjustment on canister, rebound adjustment on shaft
• 4 way remote canister system (4WRC) low & high speed compression adjustment on canister, low & high speed rebound adjustment on shaft
• All adjustment series can be upgraded for more adjustment from 1WRC to 4WRC in the future

The price excludes the cost of springs, strut mounts/brackets & bump rubbers/stops (unless the option exists to add on). However, we can configure a complete system to suit your vehicle/application.

The price indicated is a common base price for a single (x1) damper for a wide range of lengths.  The final individual price may differ by 15% to suit your specific application.

To confirm we supply you the correct unit, we will also require the following items -

• Application/category/vehicle manufacturer
• Coil over or non coil over
• Mountings - pin to eye, eye to eye, pin to T-bar, T-bar to eye
• Spring rate in use
• Motion Ratio
• Car weight & distribution front/rear weights
• Open length & closed lengths
• Special requirements
• Contact us at rob@racingshocksaustralia.com.au if you need help in obtaining the info above

Track day assistance is also available to help dial in your setup (additional costs apply).

Image may differ from actual product.
